This is a seven platform terminus for services to and from locations to the south such as Glasgow Queen Street High Level, Edinburgh Waverley and London, and locations north and west such as Kyle of Lochalsh, Thurso and Wick.
The original fine frontage onto Union Street, and a small station square, was replaced in 1968 with a plain modern structure. The Highland Railway's offices (1873-75, architects Matthews and Lawrie) were on the north side of the square and Station Hotel (originally 1855, architect Joseph Mitchell) on the south side. In the square is a memorial statue to those soldiers of the Queen's Own Highlanders killed in the Anglo-Egyptian War of 1882 (erected 1893).
The station is essentially two terminii alongside each other, one for locations to the south and east (platforms 1 to 5) and the other for locations north (platforms 5 to 7). Lines curve out to the east and to the north west connected by a non passenger line to form a triangle.
The buffer ends of the platforms are covered by glazed trainsheds and there is a concourse. The roof largely dates from 1876.
Departure from the main line platforms for Perth and Aberdeen, platforms 1-5, was controlled by 'Locomotive' signal box, dating from 1885. This box was at the east end of platform 2 on the north side and directly to the east of the south wall of the Lochgorm Works. Despite the name it did not control the works or Inverness Shed - the entry into these was controlled from Welsh's Bridge Junction Signal Box, to the east. 'Locomotive' was replaced around 1896/97 in anticipation of the opening of the Direct Line via Slochd and the resignalling which also replaced Welsh's Bridge. The box closed in 1987, replaced by the Inverness Signalling Centre.
There was also an 'Inverness Station' signal box, this was located in the 'V' of the junction at platform 5. It opened in 1898 and closed in 1917 when replaced with a ground frame. The cabin itself was relocated to Murthly to become its south box. A (then) new small cabin was erected over the ground frame, since removed.
Nearby the station are:
- Inverness Signalling Centre, in the 'V' of the junction at platform 5
- Lochgorm Works, now the locomotive depot, enclosed by the station lines and its bypass
- Inverness Goods, to the south of the station and approached from the east, now closed and the site cleared
- Inverness Shed, to the south of the station approach from the east and now closed and cleared
- Rose Street Junction, the junction between the northbound station platforms and station bypass
- Needlefield Carriage Sidings, to the north of the station bypass, approached from the east, the original carriage sheds now demolished
- Millburn Yard, marshalling sidings and the present goods sidings laid out north of the carriage sidings, approached from the east
- Inverness Harbour, to the north west of the station and near the River Ness quayside
- Welsh's Bridge Junction, junction between the eastern station approach, southern station approach, Inverness station, Lochgorm Works, bypass line, Needlefield Carriage Sidings
- Ness Viaduct, a bridge over the River Ness carrying the Far North Line
- Millburn Junction, a wartime built connection, now removed, on the Aberdeen line to give access to Millburn Yard
Inverness was at the centre of the Highland Railway, a network of largely single track line. Double track was to extend out from Inverness as far west as Clunes, east to Dalcross and south to Daviot.
Castle Stuart Platform
| Inverness Goods|
Inverness Signalling Centre
Rose Street Junction
Needlefield Carriage Sidings
Inverness Ammunition Depot
Welsh's Bridge Platform
Welsh's Bridge Junction
Inverness Bus Station
|Location names in dark blue are on the same original line.|
|09/09/1863||Inverness and Perth Junction Railway|
Line opened from Pitlochry to Aviemore, thus throughout from Inverness to Perth.
|/ /1883||Glasgow and North Western Railway|
Glasgow and North Western Railway proposed by North British Railway. The route was to have been Glasgow to Inverness via Fort William. It was not built.
|07/02/1989||[Inverness and Ross-shire Railway]|
Ness Viaduct, Inverness, collapses, separating the Thurso, Wick and Kyle of Lochalsh lines from the rest of the network. Dingwall becomes a terminus, Muir of Ord becomes a train maintenance depot and buses operate between Inverness and Dingwall while a new bridge is built.
