Forth Bridge: Another scaffolding-free shot of the Forth Bridge, this one taken on 5 November 2012. Nice and shiny in it's new paint too! See image 40857
Brian Taylor 05/11/2012

Forth Bridge

Location type

Bridge

Name and dates

Forth Bridge (1890-)

Opened on the Forth Bridge Railway.

Description

This double track bridge consists of three double cantilevers approached by viaducts at either end. Overall it is 1.5 miles long. The bridge crosses the Firth of Forth between Dalmeny and North Queensferry. The bridge is known for its red colour, originally from the red oxide paint used.

The cantilevers were engineered by Benjamin Baker and John Fowler. The approach viaducts were engineered by James Carsewell. The contractor was William Arrol. Construction began in 1882 and the bridge opened in 1890, with the Prince of Wales (the future Edward VII) driving the last ceremonial rivet.

Tags

Bridge Cantilever

External links

Canmore site record
NLS Collection OS map of 1892-1914
NLS Collection OS map of 1944-67
NLS Map




Nearby stations
New Halls
South Queensferry Halt
South Queensferry [1st]
Dalmeny
North Queensferry [1st]
North Queensferry
Port Edgar
Dalmeny [1st]
Inverkeithing [1st]
Rosyth Dockyard
Inverkeithing
Kirkliston
Dalgety Bay
Donibristle Platform
Rosyth
Battery Quarry
Port Edgar Harbour
Rosshill Shale Mine
North British Creosote Works
St Margaret^s Tunnel
Dalmeny Junction
North Queensferry Tunnel
Castlandhill Siding
Tourist/other
Hawes Pier
Forth Bridge North Signal Box
Port Edgar East Naval Pier
Port Edgar Pier
Carlingnose Submarine Mining Pier
Port Edgar West Naval Pier
Port Laing Submarine Mines Depot
Location names in dark blue are on the same original line.


Forth Bridge in figures


Whole bridge
Overall length2766 yards
Cost£ 3,000,000
'Briggers'4,600
Main structure
TowersThree
CaissonsFour per tower
Rail height over high water156 ft
Height of towers over high water361 ft
Tower main tubes diameter12 ft
Steel50,958 tons
Rivets8,000,000 (estimated)
Approach viaducts
PiersGranite
Southern viaductFour arches, ten girders
Northern viaductFive girders, three arches



Rivets


A considerable number of rivets were used in the building of the Forth Bridge. Estimates vary between 6.5 and 8 million. The last rivet was driven by the Prince of Wales on the opening day, 4 March 1890.


Chronology Dates

  /  /1879Forth Bridge Railway
Sir Thomas Bouch loses the contract to build the Forth Bridge after collapse of his Tay Bridge [1st].
  /  /1890William Arrol & Co
Complete the Forth Bridge.
  /  /1898Cowdenbeath North Junction to Lumphinnans Central Junction (North British Railway)
Line authorised, in connection with the Forth Bridge.
  /  /2000Forth Bridge Railway
Painting of the Forth Bridge's northern approach spans begins.
06/11/2001Virgin Trains
Press trip around Fife by new Virgin Voyagers. (Voyagers first crossed the Forth Bridge on the 30th of October.)
  /03/2004Edinburgh Airport Rail Link
Proposed scheme would have a station under Edinburgh Airport served by a link off the Forth Bridge Connecting Lines (North British Railway) and the Edinburgh and Glasgow Railway and the Forth Bridge lines. The layout would be southern approaches (both approached from the east) from South Gyle and Gogar combining and passing under Edinburgh Airport before dividing with a western link to Humbie Signal Box and northern link to Dalmeny South Junction. This layout would allow trains from Edinburgh Waverley and Glasgow Queen Street High Level to serve the station and the line to the north from Edinburgh to Fife, Aberdeen and Inverness over the Forth Bridge. The estimated cost was £500M.
12/01/2005Forth Bridge Railway
All First ScotRail services over the Forth Bridge are cancelled during a severe storm.
19/05/2008Stirling and Dunfermline Railway
Kincardine Branch (North British Railway)
The railway between Stirling and Alloa re-opens to passengers. The line between Stirling and Longannet Power Station via Alloa re-opens to freight providing an alternative route to the Forth Bridge.
09/12/2011Forth Bridge Railway
Painting of the Forth Bridge completed. Network Rail suggests no further painting to be required until 2031-36. A glass flake epoxy paint used by Balfour Beatty.
  /02/2019Forth Bridge Railway
A gantry is installed below the Forth Bridge for repairs to stress defects.
